The high voltage wire induction clamp is clamped on the high voltage line of cylinder with the arrow on the induction clamp pointing to the direction of the spark plug for normal working. Size:Size of induction: about 10 mm/ 0.39 inchesĪttention: The power supply is 12V with red connecting to positive and black to negative. If too late, it will cause difficult start-up or insufficient power, thus accelerated oil consumption and engine abrasion. If too early, the engine speeds up and produces "GA, GA" like metal knocking with large starting resistance, difficult engine rotation, power reduction and idling instability, trembling. It will cause the engine start-up failure if the worst come to the worst. Ignition timing directly affects the normal operation of the engine. It is able to reset the ignition timing under the normal wear of the engine for a long time, the regular replacement of timing belt and belt pulley, the decrease of cylinder pressure. This timing device with 12V working voltage is suitable for cars, motorcycles and all gasoline engines of two strokes or four strokes.Ĭapable of testing the ignition timing scale on the engine flywheel or belt pulley intuitively to adjust appropriately.Īble to detect the automotive knock suppression control system and vacuum advance angle control system, change its advance angle with the speed change. And the high quality makes it be worn hardly.
#TIMING GUN MANUAL#
They all serve the same purpose but offer different RPM ranges, ability to operate a multi-spark system and offer features such as timing manual advance, a dwell meter, and the possible option to work on four-cylinder, six-cylinder, or eight-cylinder engines.The handle is ergonomically designed with comfortable press keys, great Press feeling and easy operation. What brand manufacturers offer automotive timing lights?Īutomotive timing lights come in three styles: inductive, digital, and self-powered. Not every timing light is compatible with MSD systems, so be sure to check that the one you want can meet these requirements before purchasing. To properly measure this sequence, the timing light must be able to show the beginning of the sequence.
#TIMING GUN SERIES#
Typically, the distributor only provides a single spark for an ignition sequence, but in MSD systems, there are a series of them disbursed at a specific timing. How do timing lights help multiple spark distribution systems (MSD)? Units with a dwell meter measure for how long the coil is being charged and allow for prevention of pitting or burning due to an accurately set point gap.Adjustment knobs coupled with a tachometer allow for more precise timing measurement at different RPMs.Adjustment knobs that allow for the timing to be read at different RPMs are available on some models.It should be able to read both two-cycle and four-cycle engines. The standard timing lights come with a xenon light tube that is able to read timing when the vehicle engine is at idle.Knowing this allows adjustments to be made via manipulation of the distributor cap to make the spark plugs fire before or after the piston has reached the top dead center, depending on the malfunction or issue that needs to be fixed. By aiming this strobe light in the proper place, usually the crankshaft pulley, you will be able to read the degree markings on it, which are indicative of where the crankshaft is in its rotation and the respective pistons. Inductive timing lights, when connected properly to the car's engine and battery, detect the electricity every time the plug fires, and every time the plug fires, the timing light shoots a beam of light.
The light is powered by the vehicle it is being used to test. The light can be a stroboscope that may use a simple neon lamp or a xenon strobe lamp that provides brighter light and better use in daylight or in shop lighting. Timing lights are diagnostic tools used to observe ignition timing in vehicles with distributors and are available as self-contained units or as a part of a more comprehensive engine analytical tool. See Your Car's Diagnostics More Clearly With Automotive Timing Lights
